Weidmuller - Automation Control - IoT Gateways - IOT GW30 4G EU

Internet of Things

IoT Gateway IOT-GW30-4G-EU adalah perangkat gateway industri dengan Fast Ethernet dan proteksi IP20, dirancang untuk pemasangan DIN rail. Dilengkapi prosesor Dual Core ARM Cortex A9 (600MHz), RAM 1GB DDR3, dan Flash 4GB, perangkat ini mendukung pemrosesan data real-time dengan RTC buffered hingga 5 hari. Dibangun dengan material logam yang kokoh sesuai standar IEC 60068-2-27 (tahan guncangan), gateway ini dapat beroperasi pada suhu -20°C hingga 60°C dengan kelembaban 5–95%. Solusi ideal untuk konektivitas dan integrasi IoT di lingkungan industri.

DESKRIPSI DETAIL

General Data
• Version: IoT Gateway, Fast Ethernet, IP20, -20°C - 60°C
• Type: IOT-GW30-4G-EU
• GTIN (EAN): 4050118691689
• Shock: According to IEC 60068-2-27
• Protection degree: IP20
• Housing main material: Metal
• Protection degree: IP20
• Speed: Fast Ethernet
• Type of mounting: DIN rail

Dimensions and Weights
• Depth: 105mm
• Depth: 4.134inch
• Height: 125mm
• Height: 4.921inch
• Width: 35mm
• Width: 1.378inch
• Net weight: 500g

Temperatures
• Storage temperature: -40°C - 85°C
• Operating temperature: -20°C - 60°C
• Humidity: 5 to 95 % (non-condensing)

Environmental Product Compliance
• REACH SVHC: Lead 7439-92-1
• SCIP: 05711a2b-ba3f-4f0d-9bb3-583a06111ef4

System data
• Memory (Flash): 4GB
• Memory (RAM): 1GB DDR3
• Processor: Dual Core ARM Cortex A9, 600MHz
• Real-time clock: Capacity buffered (max 5 days)

Classifications
• ETIM 6.0: EC001099
• ETIM 7.0: EC001099
• ETIM 8.0: EC001099
• ETIM 9.0: EC001099
• ECLASS 9.0: 19-17-01-00
• ECLASS 9.1: 19-17-01-00
• ECLASS 10.0: 19-17-05-90
• ECLASS 11.0: 19-17-05-90
• ECLASS 12.0: 19-17-05-90
• ECLASS 13.0: 19-17-05-90
• ECLASS 14.0: 19-17-05-90
• ECLASS 15.0: 19-17-05-90
