THK - Precision Ballscrew BNFN
Ball Screw
THK - Precision Ballscrew BNFN
Double-nut Preload Model BNFN
Jenis yang paling umum dengan preload yang disediakan melalui spacer antara dua ball screw nuts untuk menghilangkan backlash.
DESKRIPSI DETAIL
Fitur dari produk ini adalah:
・Kombinasi berbagai diameter poros dan timah
・Jenis Stok Standar
・Standar akurasi sesuai dengan JIS
Spesifikasi:
BNFN 5510-2.5
BNFN 5510-2.5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 141 mm
Load Dynamic Rating: 33.4 kN
Load Static Rating: 97 kN
BNFN 5510-5
BNFN 5510-5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 201 mm
Load Dynamic Rating: 60.7 kN
Load Static Rating: 194 kN
BNFN 5510-7.5
BNFN 5510-7.5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 261 mm
Load Dynamic Rating: 85.9 kN
Load Static Rating: 291.1 kN
BNFN 5512-2.5
BNFN 5512-2.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 165 mm
Load Dynamic Rating: 39.3 kN
Load Static Rating: 108.8 kN
BNFN 5512-3
BNFN 5512-3
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 191 mm
Load Dynamic Rating: 46 kN
Load Static Rating: 131.3 kN
BNFN 5512-3.5
BNFN 5512-3.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 189 mm
Load Dynamic Rating: 52.4 kN
Load Static Rating: 152.9 kN
BNFN 5512-5
BNFN 5512-5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 237 mm
Load Dynamic Rating: 71.3 kN
Load Static Rating: 218.5 kN
BNFN 5512-7.5
BNFN 5512-7.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 309 mm
Load Dynamic Rating: 100.9 kN
Load Static Rating: 327.3 kN
BNFN 5516-2.5
BNFN 5516-2.5
Screw shaft outer diameter: 55 mm
Lead: 16 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 110 mm
Flange diameter: 158 mm
Overall length: 196 mm
Load Dynamic Rating: 76.1 kN
Load Static Rating: 201.9 kN
BNFN 5516-5
BNFN 5516-5
Screw shaft outer diameter: 55 mm
Lead: 16 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 110 mm
Flange diameter: 158 mm
Overall length: 292 mm
Load Dynamic Rating: 138.2 kN
Load Static Rating: 402.8 kN
BNFN 5520-2.5
BNFN 5520-2.5
Screw shaft outer diameter: 55 mm
Lead: 20 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 112 mm
Flange diameter: 158 mm
Overall length: 227 mm
Load Dynamic Rating: 76 kN
Load Static Rating: 201.9 kN
BNFN 5520-5
BNFN 5520-5
Screw shaft outer diameter: 55 mm
Lead: 20 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 112 mm
Flange diameter: 158 mm
Overall length: 347 mm
Load Dynamic Rating: 138.2 kN
Load Static Rating: 403.8 kN
BNFN 6310-2.5
BNFN 6310-2.5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 137 mm
Load Dynamic Rating: 35.4 kN
Load Static Rating: 111.7 kN
BNFN 6310-5
BNFN 6310-5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 197 mm
Load Dynamic Rating: 64.2 kN
Load Static Rating: 222.5 kN
BNFN 6310-7.5
BNFN 6310-7.5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 257 mm
Load Dynamic Rating: 90.9 kN
Load Static Rating: 334.2 kN
BNFN 6312A-2.5
BNFN 6312A-2.5
Screw shaft outer diameter: 63 mm
Lead: 12 mm
Ball center-to・center diameter: 65.25 mm
Outer diameter: 115 mm
Flange diameter: 161 mm
Overall length: 159 mm
Load Dynamic Rating: 48.1 kN
Load Static Rating: 139.2 kN
BNFN 6312A-5
BNFN 6312A-5
Screw shaft outer diameter: 63 mm
Lead: 12 mm
Ball center-to・center diameter: 65.25 mm
Outer diameter: 115 mm
Flange diameter: 161 mm
Overall length: 231 mm
Load Dynamic Rating: 87.4 kN
Load Static Rating: 278.3 kN
BNFN 6316-2.5
BNFN 6316-2.5
Screw shaft outer diameter: 63 mm
Lead: 16 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 184 mm
Overall length: 208 mm
Load Dynamic Rating: 81.1 kN
Load Static Rating: 231.3 kN
BNFN 6316-5
BNFN 6316-5
Screw shaft outer diameter: 63 mm
Lead: 16 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 184 mm
Overall length: 304 mm
Load Dynamic Rating: 147 kN
Load Static Rating: 462.6 kN
BNFN 6320-2.5
BNFN 6320-2.5
Screw shaft outer diameter: 63 mm
Lead: 20 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 180 mm
Overall length: 227 mm
Load Dynamic Rating: 81 kN
Load Static Rating: 231.3 kN
BNFN 6320-5
BNFN 6320-5
Screw shaft outer diameter: 63 mm
Lead: 20 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 180 mm
Overall length: 347 mm
Load Dynamic Rating: 147 kN
Load Static Rating: 463.5 kN
BNFN 7010-2.5
BNFN 7010-2.5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 141 mm
Load Dynamic Rating: 36.8 kN
Load Static Rating: 123.5 kN
BNFN 7010-5
BNFN 7010-5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 201 mm
Load Dynamic Rating: 66.9 kN
Load Static Rating: 247 kN
BNFN 7010-7.5
BNFN 7010-7.5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 261 mm
Load Dynamic Rating: 94.9 kN
Load Static Rating: 371.4 kN
BNFN 7012-2.5
BNFN 7012-2.5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 165 mm
Load Dynamic Rating: 43.5 kN
Load Static Rating: 139.2 kN
BNFN 7012-5
BNFN 7012-5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 237 mm
Load Dynamic Rating: 78.9 kN
Load Static Rating: 278.3 kN
BNFN 7012-7.5
BNFN 7012-7.5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 309 mm
Load Dynamic Rating: 111.7 kN
Load Static Rating: 417.5 kN
BNFN 7020-5
BNFN 7020-5
Screw shaft outer diameter: 70 mm
Lead: 20 mm
Ball center-to・center diameter: 72.7 mm
Outer diameter: 130 mm
Flange diameter: 186 mm
Overall length: 325 mm
Load Dynamic Rating: 153.9 kN
Load Static Rating: 514.5 kN
BNFN 8010-2.5
BNFN 8010-2.5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 137 mm
Load Dynamic Rating: 38.9 kN
Load Static Rating: 141.1 kN
BNFN 8010-5
BNFN 8010-5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 197 mm
Load Dynamic Rating: 70.6 kN
Load Static Rating: 283.2 kN
BNFN 8010-7.5
BNFN 8010-7.5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 257 mm
Load Dynamic Rating: 100 kN
Load Static Rating: 424.3 kN
BNFN 8012-5
BNFN 8012-5
Screw shaft outer diameter: 80 mm
Lead: 12 mm
Ball center-to・center diameter: 82.3 mm
Outer diameter: 135 mm
Flange diameter: 181 mm
Overall length: 231 mm
Load Dynamic Rating: 96.5 kN
Load Static Rating: 353.8 kN
BNFN 8020A-2.5
BNFN 8020A-2.5
Screw shaft outer diameter: 80 mm
Lead: 20 mm
Ball center-to・center diameter: 82.7 mm
Outer diameter: 143 mm
Flange diameter: 204 mm
Overall length: 227 mm
Load Dynamic Rating: 90.1 kN
Load Static Rating: 294 kN
BNFN 8020A-5
BNFN 8020A-5
Screw shaft outer diameter: 80 mm
Lead: 20 mm
Ball center-to・center diameter: 82.7 mm
Outer diameter: 143 mm
Flange diameter: 204 mm
Overall length: 347 mm
Load Dynamic Rating: 163.7 kN
Load Static Rating: 589 kN
BNFN 10020A-2.5
BNFN 10020A-2.5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 231 mm
Load Dynamic Rating: 99 kN
Load Static Rating: 368.5 kN
BNFN 10020A-5
BNFN 10020A-5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 351 mm
Load Dynamic Rating: 179.3 kN
Load Static Rating: 737 kN
BNFN 10020A-7.5
BNFN 10020A-7.5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 471 mm
Load Dynamic Rating: 253.8 kN
Load Static Rating: 1105.4 kN
Distributor Produk Otomasi dan Robotik Power Transmission & Guide Ballscrew THK Precision Ballscrew BNFN
・Kombinasi berbagai diameter poros dan timah
・Jenis Stok Standar
・Standar akurasi sesuai dengan JIS
Spesifikasi:
BNFN 5510-2.5
BNFN 5510-2.5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 141 mm
Load Dynamic Rating: 33.4 kN
Load Static Rating: 97 kN
BNFN 5510-5
BNFN 5510-5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 201 mm
Load Dynamic Rating: 60.7 kN
Load Static Rating: 194 kN
BNFN 5510-7.5
BNFN 5510-7.5
Screw shaft outer diameter: 55 mm
Lead: 10 mm
Ball center-to・center diameter: 56.75 mm
Outer diameter: 102 mm
Flange diameter: 144 mm
Overall length: 261 mm
Load Dynamic Rating: 85.9 kN
Load Static Rating: 291.1 kN
BNFN 5512-2.5
BNFN 5512-2.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 165 mm
Load Dynamic Rating: 39.3 kN
Load Static Rating: 108.8 kN
BNFN 5512-3
BNFN 5512-3
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 191 mm
Load Dynamic Rating: 46 kN
Load Static Rating: 131.3 kN
BNFN 5512-3.5
BNFN 5512-3.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 189 mm
Load Dynamic Rating: 52.4 kN
Load Static Rating: 152.9 kN
BNFN 5512-5
BNFN 5512-5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 237 mm
Load Dynamic Rating: 71.3 kN
Load Static Rating: 218.5 kN
BNFN 5512-7.5
BNFN 5512-7.5
Screw shaft outer diameter: 55 mm
Lead: 12 mm
Ball center-to・center diameter: 57 mm
Outer diameter: 105 mm
Flange diameter: 147 mm
Overall length: 309 mm
Load Dynamic Rating: 100.9 kN
Load Static Rating: 327.3 kN
BNFN 5516-2.5
BNFN 5516-2.5
Screw shaft outer diameter: 55 mm
Lead: 16 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 110 mm
Flange diameter: 158 mm
Overall length: 196 mm
Load Dynamic Rating: 76.1 kN
Load Static Rating: 201.9 kN
BNFN 5516-5
BNFN 5516-5
Screw shaft outer diameter: 55 mm
Lead: 16 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 110 mm
Flange diameter: 158 mm
Overall length: 292 mm
Load Dynamic Rating: 138.2 kN
Load Static Rating: 402.8 kN
BNFN 5520-2.5
BNFN 5520-2.5
Screw shaft outer diameter: 55 mm
Lead: 20 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 112 mm
Flange diameter: 158 mm
Overall length: 227 mm
Load Dynamic Rating: 76 kN
Load Static Rating: 201.9 kN
BNFN 5520-5
BNFN 5520-5
Screw shaft outer diameter: 55 mm
Lead: 20 mm
Ball center-to・center diameter: 57.7 mm
Outer diameter: 112 mm
Flange diameter: 158 mm
Overall length: 347 mm
Load Dynamic Rating: 138.2 kN
Load Static Rating: 403.8 kN
BNFN 6310-2.5
BNFN 6310-2.5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 137 mm
Load Dynamic Rating: 35.4 kN
Load Static Rating: 111.7 kN
BNFN 6310-5
BNFN 6310-5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 197 mm
Load Dynamic Rating: 64.2 kN
Load Static Rating: 222.5 kN
BNFN 6310-7.5
BNFN 6310-7.5
Screw shaft outer diameter: 63 mm
Lead: 10 mm
Ball center-to・center diameter: 64.75 mm
Outer diameter: 108 mm
Flange diameter: 154 mm
Overall length: 257 mm
Load Dynamic Rating: 90.9 kN
Load Static Rating: 334.2 kN
BNFN 6312A-2.5
BNFN 6312A-2.5
Screw shaft outer diameter: 63 mm
Lead: 12 mm
Ball center-to・center diameter: 65.25 mm
Outer diameter: 115 mm
Flange diameter: 161 mm
Overall length: 159 mm
Load Dynamic Rating: 48.1 kN
Load Static Rating: 139.2 kN
BNFN 6312A-5
BNFN 6312A-5
Screw shaft outer diameter: 63 mm
Lead: 12 mm
Ball center-to・center diameter: 65.25 mm
Outer diameter: 115 mm
Flange diameter: 161 mm
Overall length: 231 mm
Load Dynamic Rating: 87.4 kN
Load Static Rating: 278.3 kN
BNFN 6316-2.5
BNFN 6316-2.5
Screw shaft outer diameter: 63 mm
Lead: 16 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 184 mm
Overall length: 208 mm
Load Dynamic Rating: 81.1 kN
Load Static Rating: 231.3 kN
BNFN 6316-5
BNFN 6316-5
Screw shaft outer diameter: 63 mm
Lead: 16 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 184 mm
Overall length: 304 mm
Load Dynamic Rating: 147 kN
Load Static Rating: 462.6 kN
BNFN 6320-2.5
BNFN 6320-2.5
Screw shaft outer diameter: 63 mm
Lead: 20 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 180 mm
Overall length: 227 mm
Load Dynamic Rating: 81 kN
Load Static Rating: 231.3 kN
BNFN 6320-5
BNFN 6320-5
Screw shaft outer diameter: 63 mm
Lead: 20 mm
Ball center-to・center diameter: 65.7 mm
Outer diameter: 122 mm
Flange diameter: 180 mm
Overall length: 347 mm
Load Dynamic Rating: 147 kN
Load Static Rating: 463.5 kN
BNFN 7010-2.5
BNFN 7010-2.5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 141 mm
Load Dynamic Rating: 36.8 kN
Load Static Rating: 123.5 kN
BNFN 7010-5
BNFN 7010-5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 201 mm
Load Dynamic Rating: 66.9 kN
Load Static Rating: 247 kN
BNFN 7010-7.5
BNFN 7010-7.5
Screw shaft outer diameter: 70 mm
Lead: 10 mm
Ball center-to・center diameter: 71.75 mm
Outer diameter: 125 mm
Flange diameter: 167 mm
Overall length: 261 mm
Load Dynamic Rating: 94.9 kN
Load Static Rating: 371.4 kN
BNFN 7012-2.5
BNFN 7012-2.5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 165 mm
Load Dynamic Rating: 43.5 kN
Load Static Rating: 139.2 kN
BNFN 7012-5
BNFN 7012-5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 237 mm
Load Dynamic Rating: 78.9 kN
Load Static Rating: 278.3 kN
BNFN 7012-7.5
BNFN 7012-7.5
Screw shaft outer diameter: 70 mm
Lead: 12 mm
Ball center-to・center diameter: 72 mm
Outer diameter: 128 mm
Flange diameter: 170 mm
Overall length: 309 mm
Load Dynamic Rating: 111.7 kN
Load Static Rating: 417.5 kN
BNFN 7020-5
BNFN 7020-5
Screw shaft outer diameter: 70 mm
Lead: 20 mm
Ball center-to・center diameter: 72.7 mm
Outer diameter: 130 mm
Flange diameter: 186 mm
Overall length: 325 mm
Load Dynamic Rating: 153.9 kN
Load Static Rating: 514.5 kN
BNFN 8010-2.5
BNFN 8010-2.5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 137 mm
Load Dynamic Rating: 38.9 kN
Load Static Rating: 141.1 kN
BNFN 8010-5
BNFN 8010-5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 197 mm
Load Dynamic Rating: 70.6 kN
Load Static Rating: 283.2 kN
BNFN 8010-7.5
BNFN 8010-7.5
Screw shaft outer diameter: 80 mm
Lead: 10 mm
Ball center-to・center diameter: 81.75 mm
Outer diameter: 130 mm
Flange diameter: 176 mm
Overall length: 257 mm
Load Dynamic Rating: 100 kN
Load Static Rating: 424.3 kN
BNFN 8012-5
BNFN 8012-5
Screw shaft outer diameter: 80 mm
Lead: 12 mm
Ball center-to・center diameter: 82.3 mm
Outer diameter: 135 mm
Flange diameter: 181 mm
Overall length: 231 mm
Load Dynamic Rating: 96.5 kN
Load Static Rating: 353.8 kN
BNFN 8020A-2.5
BNFN 8020A-2.5
Screw shaft outer diameter: 80 mm
Lead: 20 mm
Ball center-to・center diameter: 82.7 mm
Outer diameter: 143 mm
Flange diameter: 204 mm
Overall length: 227 mm
Load Dynamic Rating: 90.1 kN
Load Static Rating: 294 kN
BNFN 8020A-5
BNFN 8020A-5
Screw shaft outer diameter: 80 mm
Lead: 20 mm
Ball center-to・center diameter: 82.7 mm
Outer diameter: 143 mm
Flange diameter: 204 mm
Overall length: 347 mm
Load Dynamic Rating: 163.7 kN
Load Static Rating: 589 kN
BNFN 10020A-2.5
BNFN 10020A-2.5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 231 mm
Load Dynamic Rating: 99 kN
Load Static Rating: 368.5 kN
BNFN 10020A-5
BNFN 10020A-5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 351 mm
Load Dynamic Rating: 179.3 kN
Load Static Rating: 737 kN
BNFN 10020A-7.5
BNFN 10020A-7.5
Screw shaft outer diameter: 100 mm
Lead: 20 mm
Ball center-to・center diameter: 102.7 mm
Outer diameter: 170 mm
Flange diameter: 243 mm
Overall length: 471 mm
Load Dynamic Rating: 253.8 kN
Load Static Rating: 1105.4 kN
Distributor Produk Otomasi dan Robotik Power Transmission & Guide Ballscrew THK Precision Ballscrew BNFN
PRODUK UNGGULAN KAMI
THK - BL Series
THK Link Ball Model BL Link Ball adalah bantalan geser berbentuk bola dengan ball stud yang memberikan pengoperasian yang mulus dengan celah minimal. Dengan ketahanan abrasi yang luar biasa dan sudut osilasi yang besar, produk ini cocok untuk mekanisme g...
THK - BNK
BNK Finished Shaft Ends Model BNK Untuk model ini, screw shafts dengan sebuah screw shaft outer berdiameter 4 hingga 25 mm dan sebuah lead 1 hingga 20 mm dapat menjadi standard....
THK - Caged Ball LM Guide EPF
THK - Caged Ball LM Guide EPF Panduan LM (Linear Motion Guide) adalah produk utama kami, yang untuk pertama kalinya di dunia menggabungkan komponen dengan gerakan linear rolling ke dalam penggunaan praktis. Produk ini memungkinkan pengembangan mesin deng...
THK - Caged Ball LM Guide Models SPR - SPS
THK - Caged Ball LM Guide Model SPR - SPS LM Guide (Linear Motion Guide) adalah produk andalan THK yang pertama kali memperkenalkan komponen dengan gerakan linear rolling ke dalam aplikasi praktis di seluruh dunia. Produk ini memungkinkan pengembangan me...
THK - Caged Ball LM Guide SCR
THK - Caged Ball LM Guide SCR LM Guide (Linear Motion Guide) adalah produk utama kami yang untuk pertama kalinya di dunia memasukkan komponen dengan gerakan linear rolling ke dalam penggunaan praktis. Produk ini memungkinkan pengembangan mesin dengan pre...
THK - Caged Ball LM Guide SHS
THK - Caged Ball LM Guide SHS LM Guide (Linear Motion Guide) adalah produk utama kami yang menggabungkan komponen dengan gerakan rolling linear untuk pertama kalinya di dunia ke dalam aplikasi praktis. Produk ini memungkinkan pengembangan mesin presisi t...
