Pudu Robotics - Delivery Robot - Puductor 2

No-contact operations, safety means everything

COVID-19 has changed our way of living. No-contact operations will be crucial for the foreseeable future. Pudu Robotics provides multiple solutions to battle the negative impact from the pandemic. With true no-contact functions and double disinfection modules,Puductor 2, the UV cleaning robot combined with air disinfection machine, minimizes the risk of cross infection and improves sanitary condition for indoor environments.

Features
• 2L/H Ultrasonic Dry Mist Disinfection
• 188μW/cm² UV-C Disinfection
• Max 6H Disinfection Time
• 15L Reservoir Capacity
• 360° Sterilization
• Boil-dry Protection and Low-level Warning
• Automatic Localization and Navigation System
• Automatic Recharging

Ultrasonic Dry Mist Disinfection

15L - Reservoir Capacity
15L huge volume: Customers do not need to replenish the disinfectant solution frequently.

≤ 10 μm - Dry Disinfectant Particles
≤10µm dry disinfectant particles ensuring full contact with microorganisms.

2.0 L/h - Max Atomization Rate[1]
4 mist outputs(adjuestable): According to the different application scenarios, the dry mist output can be conveniently adjusted to achieve excellent disinfection effect.

Ultraviolet C Disinfection

• 99.99% Disinfection Rate
4 x 36w ozone-free UV lamp equipped, achieving an industry leading ultraviolet illumination of 188μW/cm² [2] at 1 meter. The UV-C lamp is highly effective against most types of bacteria and viruses, securing a 99.99% disinfection rate.

• Intelligent UV-C Lamp Protector
Enclosed cabin with motorized interlocking mechanism, providing protection to the lamp while not operating.

Automatic Recharging
The total battery capacity is 51.2Ah, for a maximum disinfection time of up to 6h, which can support the disinfection of 12-15 rooms (20㎡/room). Puductor 2 is equipped with a docking station. To make sure that the robot is fully charged and ready for the next task, time saving as it requires no involvement from your staff.

Boil-dry Protection - Low-level Warning
• Liquid level safety detector in the ultrasonic chamber, the atomization would be terminated automatically when the liquid level is lower than the safety level.
• Real-time liquid level protector in the solution tank, reminding user to replenish solution when the liquid level is low.

Motion Sensor
Equipped with millimeter wave motion sensor ,the robot will shut down the UV lamps and spraying automatically if it detects a person within 3 meters.

Pudu Management Platform
• Remote Access
Remote terminal control of robot operation, task management, and work report printing.
• Automatic Work Report Generation
work reports generated automatically, check disinfection status of target areas.

Laser SLAM Self-Driving Solution
• Able to move freely in a 100,000m² space
• Detection range up to 40m
• Real-time positioning error less than 10cm

3D Obstacle Avoidance Technology
• INTEL® REALSENSE™ RGBD camera
• Powerful 3D perception
• Accurately detect obstacles, stopping within a reaction time of 0.5 seconds

Customer Value
• Hospitals
• Campuses
• Government Hall
• Transportations
• Hotel
• Bank

Workflow
Automatic Mode
1. The staff checks the capacity of the disinfectant solution.
2. The staff sets disinfection tasks.
Cruise Mode: total disinfection time，driving path and disinfection method
Fixed-point Mode: single point/multi-point disinfection and disinfection method
3. Puductor 2 automatically reaches the initial point of work.
4. Puductor 2 begins to count down, and notifies people to stay away from the disinfection areas.
5. Puductor 2 completes the task as programmed or the staff terminates the task remotely.
6. Puductor 2 automatically returns to the charging dock.

Quick Mode
1. The staff manually pushes the Puductor 2 to the disinfection point.
2. The staff checks the capacity of the disinfectant solution.
3. The staff sets disinfection tasks (total disinfection time, disinfection method).
4. Puductor2 begins to count down, and notifies people to stay away from the disinfection areas.
5. Puductor 2 completes the task as programmed or the staff terminates the task remotely.
6. The staff manually pushes Puductor 2 back to the charging dock.

Specification
• Machine Dimension: 544x538x1290mm
• Machine Weight: 60kg
• Battery Capacity: 51.2Ah
• Reservoir Capacity: 15L
• Irradiation Intensity at 1 Meter Distance: 188 μW/cm², UV-C(254nm)
• Effective Disinfection Distance: 3 meters
• Disinfection Time: Max 6H (Automatic Recharging)
• Cruise Speed: 0.1-1.2m/s （Adjustable）
• Disinfectant Solution: Hydrogen Peroxide( H2O2)，Hypochlorous Acid( HClO)，Chlorine Dioxide(ClO₂)，etc.
• Working Voltage: 24V
• Motion Sensor: Yes
• UV-C Lamp Protector: Yes
• Solution Inlet& Outlet: Yes
• Max Climbing Angle: 5°
