Ball Screw

BNS
Precision Ball Screw / Spline

Linear-Rolling Motion Model BNS
Stroke/Rotary unit yang memiliki Ball Screw grooves dan sebuah Ball Spline groove bersilangan satu sama lain pada sebuah single shaft. Nuts dari Ball Screw dan Ball Spline didedikasikan support bearings, melekat secara langsung pada circumference dari nuts.


Fitur dari produk ini adalah:
- Kombinasi berbagai diameter poros dan timah
- Jenis Stok Standar
- Standar akurasi sesuai dengan JIS

BNS 1616
Screw shaft outer diameter: 16 mm
Lead: 16 mm
Ball center-to-center diameter: 16.65 mm
Ball Screw Unit Outer diameter: 52   mm
Ball Screw Unit Flange diameter: 68 mm
Ball Screw Unit Length: 43.5 mm
Ball Spline Outer diameter: 52   mm
Ball Spline Flange diameter: 68 mm
Ball Spline Length: 50 mm

BNS 2020
Screw shaft outer diameter: 20 mm
Lead: 20 mm
Ball center-to-center diameter: 20.75 mm
Ball Screw Unit Outer diameter: 62   mm
Ball Screw Unit Flange diameter: 78 mm
Ball Screw Unit Length: 54 mm
Ball Spline Outer diameter: 56   mm
Ball Spline Flange diameter: 72 mm
Ball Spline Length: 63 mm

BNS 2525
Screw shaft outer diameter: 25 mm
Lead: 25 mm
Ball center-to-center diameter: 26 mm
Ball Screw Unit Outer diameter: 72   mm
Ball Screw Unit Flange diameter: 92 mm
Ball Screw Unit Length: 65 mm
Ball Spline Outer diameter: 62   mm
Ball Spline Flange diameter: 78 mm
Ball Spline Length: 71 mm

BNS 3232
Screw shaft outer diameter: 32 mm
Lead: 32 mm
Ball center-to-center diameter: 33.25 mm
Ball Screw Unit Outer diameter: 80   mm
Ball Screw Unit Flange diameter: 105 mm
Ball Screw Unit Length: 80 mm
Ball Spline Outer diameter: 80   mm
Ball Spline Flange diameter: 105 mm
Ball Spline Length: 80 mm

BNS 4040
Screw shaft outer diameter: 40 mm
Lead: 40 mm
Ball center-to-center diameter: 41.75 mm
Ball Screw Unit Outer diameter: 110   mm
Ball Screw Unit Flange diameter: 140 mm
Ball Screw Unit Length: 98 mm
Ball Spline Outer diameter: 100   mm
Ball Spline Flange diameter: 130 mm
Ball Spline Length: 100 mm

BNS 5050
Screw shaft outer diameter: 50 mm
Lead: 50 mm
Ball center-to-center diameter: 52.2 mm
Ball Screw Unit Outer diameter: 120   mm
Ball Screw Unit Flange diameter: 156 mm
Ball Screw Unit Length: 126 mm
Ball Spline Outer diameter: 120   mm
Ball Spline Flange diameter: 156 mm
Ball Spline Length: 125 mm
