Ball Screw

DKN
Precision

Slim nut Model DKN
Sekerup tipe-deflektor di mana preload diberikan melalui spacer antara dua sekrup sekrup bola untuk mencapai pembebanan aksial di bawah nol (di bawah preload).


Fitur dari produk ini adalah:
- Kombinasi berbagai diameter poros dan timah
- Jenis Stok Standar
- Standar akurasi sesuai dengan JIS

Spesifikasi:
DKN 4020-3
DKN 4020-3
Screw shaft outer diameter: 40 mm
Lead: 20 mm
Ball center-to- center diameter: 41.75 mm
Outer diameter: 62 mm
Flange diameter: 104 mm
Overall length: 223 mm
Load Dynamic Rating: 29.4 kN
Load Static Rating: 69.3 kN

DKN 5020-3
DKN 5020-3
Screw shaft outer diameter: 50 mm
Lead: 20 mm
Ball center-to- center diameter: 52.25 mm
Outer diameter: 75 mm
Flange diameter: 129 mm
Overall length: 243 mm
Load Dynamic Rating: 44.2 kN
Load Static Rating: 108.8 kN

DKN 6320-3
DKN 6320-3
Screw shaft outer diameter: 63 mm
Lead: 20 mm
Ball center-to- center diameter: 65.7 mm
Outer diameter: 95 mm
Flange diameter: 159 mm
Overall length: 243 mm
Load Dynamic Rating: 83.5 kN
Load Static Rating: 229.3 kN
