Robot Accessories

Mech Eye Industrial 3D Camera
High precision & detail-rich 3D imaging for a broad range of objects.

Our model options can satisfy diverse practical needs (ambient light resistance, high precision, high scanning speed, small size, etc.).

Mech Eye PRO M Industrial 3D Camera
• High accuracy
• Extended FOV
• Detail-rich 3D point cloud images
• Rapid image acquisition
• Designed for medium-range robotic applications

Product Advantages
• Aluminum Alloy Shell Design
• Stable and Reliable Scanning Performance
• Precision Options Meet Various Distance Requirements
• Plug & Play Easy Setup
• Dust and Water Proof
• Multiple Camera Models for Various Situations

Typical Point Clouds
• Track Links
• Colored Cartons
• Gearbox Housings
• Business Cards (Color Rendered by Height)

Other Point Clouds
• Colored Goods
• Various Groceries
• Tightly-Packed Sacks with Patterns
• Multicolored Office Supplies
• Objects with Dark Surfaces
• Reflective Objects
• Metal Parts of Different Shapes
• Tightly-Stacked Track Shoes
• Various Small Workpieces
• Small Screws
• Circuit Board
• Steell Plates
• Wheel Hub
• Totes
• Screw & Nuts

Specification
• Model: PRO M
• Optimal scanning range (mm): 1000 - 2000
• Near FOV (mm): 800×450 @ 1.0 m
• Far FOV (mm): 1500×890 @ 2.0 m
• Resolution: 1920×1200
• Megapixels: 2.3 MP
• *Point Repeatability Z (σ): 0.2 mm @ 2 m
• ***VDI/VDE Accuracy: 0.2 mm @ 2 m
• Typical Capture Time: 0.3 - 0.6 s
• Baseline: 270 mm
• Dimensions: 353×57×100 mm
• Weight（kg): 1.9
• Operating Temperature: 0 - 45℃
• Communication Interface: Ethernet
• Image Sensor: Sony CMOS for High-end Machine Vision
• Power Supply: 24V DC
• Safety and EMC: CE/FCC/VCCI
• Laser Safety Level: /
• Protection Class: IP65
• Cooling: Passive
• Remark:
*The standard deviation of the single point Z value for 100 measurements. The measurement target is a ceramic plate.
**The standard deviation of the difference of the average Z value in two local regions for 100 measurements. The measurement target is a ceramic plate.
***Refer to VDI/VDE2634 Part II.

Solutions
• Depalletizing and Palletizing
• Machine Tending
• Piece Picking
• Bin Picking
• Assembly, Locating, and Gluing
